Wheel Loader Hot Sale For China
Product Details
Basic Info.
Model NO.:XJ935II
Type:Small Loader
Usage:Special Type
Scraper Type:Tractor-Scraper
Transmission:Hydraulic Transmission
Walking Mode:Wheeled
Load and Unload Method:Front Discharge
Engine Power:74~147kw
Certification:CE, ISO9001: 2000
Condition:New
Color:Yellow
Rated Load:3tons
Engine:Weichai or Cummins
Bucket Size:1.8m3
Service:1year
Export Markets:Global
Additional Info.
Trademark:XIAJIN MACHINERY
Packing:Pack in Container or Ship by Whole Machine
Standard:CE /ISO
Origin:Xiamen
HS Code:84295100
Production Capacity:1500 Set/Year
Product Description
XJ935II Mini loader
Superior Performance
The rated payload of XJ935II wheel loader is 3 tons, and the rated bucket capacity is 1.8m3. It is a medium size wheel loader, and it is suitable for mine, water conservancy construction site, infrastructural construction, material loading/unloading fuel, road construction site and other work sites. The appearance is compact and nice. Good cost performance will help you create more fortune.
1. Hydraulic steering system makes the turning easier;
2. Frame style chassis structure, simple in structure and accessible in operation environment;
3. Front and rear frames use long span connecting structure for reducing the stress in hitch pin;
4. Anti-abrasion integral cutting edge with teeth and adapters, prolong the life of bucket;
5. Long wheelbase and centrally symmetrical structure make the front and rear tracks superposed on each other for extending the life of tire;
6. Max dumping clearance is 3330mm, which can meet the loading demand of heavy truck.
| Item | Parameter | Unit | |
|---|---|---|---|
| Rated load | 5 | t | |
| Bucket capacity | 3 | m³ | |
| Dumping height | 3090 | mm | |
| Dumping distance | 1130 | mm | |
| Max.drawing force | 170 | kN | |
| Max. traction | 165 | kN | |
| Dimension | 8185×3000×3465 | mm | |
| Operating weight | 17200 | kg | |
| Boom lifting time | ≤6.0 | ≤6.0 | |
| Total time of three devices | 11 | s | |
| Wheelbase | 3300 | s | |
| Min. turning radius (bucket outer) | 6910 | mm | |
| Rated power | 162 | kW | |
| Travel speed | I Gear (Forward/Backward) | 0-11.5/16.5 | km/h |
| II Gear (Forward) | 0-38 | km/h | |
| Long boom parameter | |||
| Item | Standard bucket | Coal bucket | |
| Bucket capacity | 2.7m³ | 3.5 | |
| Rated load | 4.5t | 4.0t | |
| Dumping height | 3710mm | 3550mm | |
| Dumping distance | 1180mm | 1300mm | |
| Dimension | 8870×3000×3350 | 8870×3000×3465 | |
| Attachment parameter | |||
| Attachment parameter-snow plow | |||
| Pushing snow width | 3800 | mm | |
| Horizontal rotary angle | ±38 | ° | |
| Vibrating angle | ±6 | ° | |
| Obstacle crossing height | 0~150 | mm | |
| Rated power | 162 | KW | |
| Attachment parameter-clamp | |||
| Dumping height | 3241 | ||
| Dumping distance | 1902 | ||
| Min. circle diameter and max. opening | |||
| Basic model | ¢800×1990 | ||
| IV model | ¢430×2000 | ||
| Attachment parameter-Sliding fork | |||
| Fork folding angle | 20 | ° | |
| Attachment length | 2053 | mm | |
| Attachment width | 2516 | mm | |
| Attachment height | 1200 | mm | |
| Fork teeth length | 1200 | mm | |
| Attachment parameter-Side dumping | |||
| Bucket width | 3000 | mm | |
| Dimension | 8310×3040×3465 | mm | |
| Dumping height(straight/side) dumping | 2960/4125 | mm | |
| Dumping distance(straight/side) dumping | 1272/105 | mm | |
| Lifting height(straight/side) dumping | 5407/6830 | mm | |
