Product Description:
We own the consummate equipments,advanced craft and technology,and high precision testing instruments.In this way,it greately enhances the machining accuracy,effectively guarantes the superior quality of the goods,reducess the product manufacture cycle.It continuously lifts up the product quality through the technical innovation.Our products are well-received by vast customers.
Bearing accuracy refers to accuracy on dimension and rotation.According to national standard,the bearing accuracy is divided into five class:P0,P6,P5,P4,P2.All of them are equivalent to ISO standard.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| um |
|
|
|
| Vdp |
|
|
|
|
|
|
|
|
△dmp | 9 | 0，1 | 2，3，4 | Vdmp | Kia | Sd | Sia | △Bs | VBs |
|
|
d(mm) | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P5 | P4 | P2 | P5 | P4 | P2 | P0,P6 | P5 | P2 | P0 | P6 | P5 | P4 | P2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Max | Min |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.5 | 10 | 0 | -8 | 0 | -7 | 0 | -5 | 0 | -4 | 0 | -2.5 | 10 | 9 | 5 | 4 | 2.5 | 8 | 7 | 4 | 3 | 2.5 | 6 | 5 | 4 | 3 | 2.5 | 6 | 5 | 3 | 2 | 1.5 | 10 | 6 | 4 | 2.5 | 1.5 | 7 | 3 | 1.5 | 7 | 3 | 1.5 | 0 | -120 | 0 | -40 | 0 | -40 | 15 | 15 | 5 | 2.5 | 1.5 |
|
|
10 | 18 | 0 | -8 | 0 | -7 | 0 | -5 | 0 | -4 | 0 | -2.5 | 10 | 9 | 5 | 4 | 2.5 | 8 | 7 | 4 | 3 | 2.5 | 6 | 5 | 4 | 3 | 2.5 | 6 | 5 | 3 | 2 | 1.5 | 10 | 7 | 4 | 2.5 | 1.5 | 7 | 3 | 1.5 | 7 | 3 | 1.5 | 0 | -120 | 0 | -80 | 0 | -80 | 20 | 20 | 5 | 2.5 | 1.5 |
|
|
18 | 30 | 0 | -10 | 0 | -8 | 0 | -6 | 0 | -5 | 0 | -2.5 | 13 | 10 | 6 | 5 | 2.5 | 10 | 8 | 5 | 4 | 2.5 | 8 | 6 | 5 | 4 | 2.5 | 8 | 6 | 3 | 2.5 | 1.5 | 13 | 8 | 4 | 3 | 2.5 | 8 | 4 | 1.5 | 8 | 4 | 2.5 | 0 | -120 | 0 | -120 | 0 | -120 | 20 | 20 | 5 | 2.5 | 1.5 |
|
|
30 | 50 | 0 | -12 | 0 | -10 | 0 | -8 | 0 | -6 | 0 | -2.5 | 15 | 13 | 8 | 6 | 2.5 | 12 | 10 | 6 | 5 | 2.5 | 9 | 8 | 6 | 5 | 2.5 | 9 | 8 | 4 | 3 | 1.5 | 15 | 10 | 5 | 4 | 2.5 | 8 | 4 | 1.5 | 8 | 4 | 2.5 | 0 | -120 | 0 | -120 | 0 | -120 | 20 | 20 | 5 | 3 | 1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| um |
|
|
| | VDp |
| Kia |
|
|
|
|
|
D | △Dmp | Vdp | 、 | VDmp | Kea | SD | Sea | △Cs | VCs |
|
(mm) |
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 9 | 0，1 | 2，3，4 | 2，3，4 | 0，1，2，3，4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P0 | P6 | P5 | P4 | P2 | P0 | P6 | P5 | P4 | P2 | P5 | P4 | P2 | P5 | P4 | P2 |
| P0 | P6 | P5 | P4 | P2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.5 | 18 | 0 | -8 | 0 | -7 | 0 | -5 | 0 | -4 | 0 | -2.5 | 10 | 9 | 5 | 4 | 2.5 | 8 | 7 | 4 | 3 | 2.5 | 6 | 5 | 4 | 3 | 2.5 | 10 | 9 | 6 | 5 | 3 | 2 | 1.5 | 15 | 8 | 5 | 3 | 1.5 | 8 | 4 | 1.5 | 8 | 5 | 1.5 | d△Bs | dVBs | 5 | 2.5 | 1.5 |
|
18 | 30 | 0 | -9 | 0 | -8 | 0 | -6 | 0 | -5 | 0 | -4 | 12 | 10 | 6 | 5 | 4 | 9 | 8 | 5 | 4 | 4 | 7 | 6 | 5 | 4 | 4 | 12 | 10 | 7 | 6 | 3 | 2.5 | 2 | 15 | 9 | 6 | 4 | 2.5 | 8 | 4 | 1.5 | 8 | 5 | 2.5 | 5 | 2.5 | 1.5 |
|
30 | 50 | 0 | -11 | 0 | -9 | 0 | -7 | 0 | -6 | 0 | -4 | 14 | 11 | 7 | 6 | 4 | 11 | 9 | 5 | 5 | 4 | 8 | 7 | 5 | 5 | 4 | 16 | 13 | 8 | 7 | 4 | 3 | 2 | 20 | 10 | 7 | 5 | 2.5 | 8 | 4 | 1.5 | 8 | 5 | 2.5 | 5 | 2.5 | 1.5 |
|
50 | 80 | 0 | -13 | 0 | -11 | 0 | -9 | 0 | -7 | 0 | -4 | 16 | 14 | 9 | 7 | 4 | 13 | 11 | 7 | 5 | 4 | 10 | 8 | 7 | 5 | 4 | 20 | 16 | 10 | 8 | 5 | 3.5 | 2 | 25 | 13 | 8 | 5 | 4 | 8 | 4 | 1.5 | 10 | 5 | 4 | 6 | 3 | 1.5 |
|
80 | 120 | 0 | -15 | 0 | -13 | 0 | -10 | 0 | -8 | 0 | -5 | 19 | 16 | 10 | 8 | 5 | 19 | 16 | 8 | 6 | 5 | 11 | 10 | 8 | 6 | 5 | 26 | 20 | 11 | 10 | 5 | 4 | 2.5 | 35 | 18 | 10 | 6 | 5 | 9 | 5 | 2.5 | 11 | 6 | 5 | 8 | 4 | 2.5 |
|
- Q:6207, deep groove ball bearings can withstand the axial force of how much?
- I am wholesale bearings
- Q:In the new standard, deep groove ball bearing type code name is 6, but I often see 16 to start with deep groove ball bearing code, such as 16005, I don't know what this 16 finger meanIn the mechanical manual, 16005 and 6005 are the same in diameter and outer diameter, but the bearing width is different. I just don't understand. What do you mean by 16?Isn't there a width code in the bearing model? And most of the bearings in the introduction, only that 6 represents deep groove ball bearings, need not appear 16 this code. But I checked, someone said, "16" means deep groove ball bearings which can be subjected to greater axial force. I wonder if it is?
- As mentioned above, 16 is a thin walled bearing. As in the 68 series of 69 series, it belongs to the thin wall bearing.
- Q:Are deep groove ball bearings rolling bearings?
- As the name suggests, rolling bearings
- Q:A deep groove ball bearing model with an outer diameter of 8.5 cm and an inner diameter of 4.5 cm
- Internal diameter 45mm external diameter 85mm wide 19mm corresponding model 6209
- Q:What are the dimensional tolerances for deep groove ball bearings?
- Deep groove ball bearings are radial bearings. In general, the upper and outer tolerance of bearings is 0, and the lower difference is a negative value. Such as deep groove ball bearings 6206, the bore diameter is 30mm, the deviation is 0~-0.01mm; the outer diameter of the bearing is 62mm, the deviation is 0~-0.013mm. The specific bearing tolerance is determined according to the standard size of the bearing and the basic dimensions.
- Q:Deep groove ball bearing 6314-2Z/6P, what does the "2Z/6P" behind mean?
- 2Z refers to both sides of the bearing6P did P6 enter an error? For example, "P6" means that the tolerance level of the bearings conforms to the standard class 6.
- Q:At present only rough calculation is used to choose what kind of bearings. Load 5 ton car, four wheels, need four bearings. What kind of bearings need radial load?.
- I can't, but I know that the selling of bearings will be, if it is the standard bearings, he has a parameter, you say you want to buy Bearings, and then ask someone to help you check it
- Q:Compared with plain bearings, what are the advantages and disadvantages of deep groove ball bearings?
- 2, radial clearance is relatively small, radial angular contact bearings can be pre tightened, can be used to eliminate pre clearance clearance, high precision operation;3, under normal conditions, the efficiency of rolling bearings and liquid power lubrication bearings, but the mixed lubrication bearings higher;4, for the same size of the shaft diameter, the rolling bearing is wider than the sliding bearing, so that the axial structure of the machine is compact;5, a high degree of standardization, mass production, consumption of lubricants less, easy to seal, easy to maintain, do not need to use non-ferrous metals, low cost.Two, compared with the sliding bearing, deep groove ball bearings shortcomings:1, vibration and noise;2. Radial dimensions larger than plain bearings;3 、 poor ability to withstand impact loading;4 、 under high speed and heavy load, the bearing life is low.
- Q:See a lot of deep groove ball bearings, inner circle interference fit, the outer ring and hole clearance gap, the gap is roughly 0.04mm, what's the advantage of this cooperation? The hole is aluminum and the shaft is made of steel. If there is a gap, what is the meaning of the bearing accuracy?
- Deep groove ball bearing is rolling bearing between the shaft and the bearing to rotate with each other, because the bearing is standard, so the inner coordination is the basic hole system (Zhou Chengkong diameter standard), with the outer ring and the hole seat is the axis system (outer diameter is a standard, then as a shaft diameter). With the way a clearance fit, fit, precision bearings in bearing production come out after certain, see the description of the code bearing. As for why you are talking about aluminum, I don't understand.
- Q:What are deep groove ball bearings suitable for automotive parts?
- 1, the most representative rolling bearings, wide range of uses2 can bear radial load and two-way axial load3 、 suitable for high speed rotating and low noise, low vibration occasions4, with steel plate dust cover or rubber sealing ring sealed type bearings, in advance filled with a proper amount of grease{mainly using retainer plate, steel plate holder (wave shape, crown)... Single row; S shape... Double column)Copper alloy or phenolic resin theft holder, synthetic resin forming cage{main use} car: rear wheel, transmission, electrical deviceAppliance: General Motors, household appliancesOther: instrumentation, internal combustion engines, construction machinery, railway vehicles, shipping machinery, agricultural machinery, various industrial machinery
