T-Type Rubber Gasket For Ductile Iron Drainage Pipeline

Ref Price:
Loading Port:
China Main Port
Payment Terms:
TT or LC
Min Order Qty:
100 PCS pc
Supply Capability:
10000 PCS Per Month pc/month

OKorder Service Pledge

Quality Product

Order On-line Tracking

Timely Delivery

OKorder Service Pledge

Credit Rating

Credit Services

Credit Purchasing

Share to:

Product Description:



Specifications of T-Type Rubber Gasket For Ductile Iron Drainage Pipeline



  1. Products: Various rubber ring and mat,mostly are European and Amercian standards which are widely used.

  2. Standard: Suitable for pipe fittings,flanges etc. of BSEN545, BSEN598, BSEN4504 PN 16,BSEN4772,ISO2531,AWWA110/C153 etc.

  3. Size: DN80-DN1600

  4. Availability of the product: Pipes and fittings seal connecting, suitable for cold water ,hot water ,and gas applications erection work etc.



Push-on Type rubber gasket

The T-Type rubber gaskets of our brand have been extensively used in the distribution of water, oil and gas as well as the pressurized transmission of other liquids and have become the preferred product of the industry of a number of industries at home and abroad, including companies of ductile iron pipe, cast pipe fittings, the water diversion works of water-supply companies, water projects, municipal gas distribution projects, sewage treatment plant and community construction.
According to different types of media and operation temperatures, customers can select gaskets of the different materials(EPDM rubber, natural rubber, fluoro rubber, butyl rubber, chloroprene rubber). They are resistant to ozone aging with a life of up to 50 years, as same as the useful life of pipelines.



T-Type rubber gasket of EPDM materials

T-Type rubber gasket cross-sections are in the horseshoe-shape and spherical shape, whose materials of two different sections are compounded and vulcanized through mold pressing. At the time of interface installation, firstly, the flange of gasket horseshoe-shaped  parts is embedded into the pipeline socket groove for positioning, then inserting the socket end into the gasket of along the axis direction, thus the spherical  parts of gaskets in the annular clearance of spigots are compressed to produce a resistance in order to achieve the sealing of the flexible interface. Compared with the ordinary T-Type.
Rubber gaskets of EPDM materials are featured by high stability, weather resistance, ozone resistance, chemical resistance, high-low temperature, excellent performance of elasticity and compressive deformation.



Large-diameter ductile iron pipe T-shape rubber gasket

This kind of rubber gaskets are made from two rubbers of different hardness: the hard rubber is used to fix the rubber gasket fixed in the spigot. The compressed deformation of soft rubbers is featured by excellent sealing performance. In the design of T-Type interface have following features: 1. during installation, due to the space of the socket d4 face and the spigot d5 surface, making the rubber gasket compressed to achieve good sealing effects; secondly, with the water pressure increases, the greater the acting force on the rubber gasket, the better the sealing performance.



Applications of T-Type Rubber Gasket For Ductile Iron Drainage Pipeline

T-Type Rubber Gasket For Ductile Iron Drainage Pipeline are widely used in lots of industries: It is mainly used in Ship, car, vehicle door, computer cabinet, Golf cart truck, mechanical protection, Playground equipment helmet and so on.

Main Usage: Outdoor weather resistant uses. Automotive brake systems. Automobile cooling systems. Water applications. Low torque drive belts,and so on.

Function: waterproof, Sealing, Anti-pest, Anti-wind, Anti-collision, Anti-noise, Anti-smoke, Anti-Oil



Packing & Delivery of T-Type Rubber Gasket For Ductile Iron Drainage Pipeline


1. Package of fumigated wooden box for exports;
2. Package of general woven bog;
3. Wooden pallet cardboard;
4. Ton bag packaging;
5. Wood pallet



Characteristics of T-Type Rubber Gasket For Ductile Iron Drainage Pipeline

1: Microwave curing time, surface bright and clean and no contact mark
2: Has good flexibility and resistance to compression deformation, and excellent aging properties
3: Excellent flame retardant properties, low smoke, low toxicity
4: Product out of stable, high precision measurements
5:Anti-High and low temperature.
