Fuel Tanker 8000L 4X2 Oil Tank Truck
Product Details
Basic Info.
Model NO.:EQ1121
Transmission Type:Manual
Power:Diesel
Load Capacity:1-10t
Emission Standard:Euro 3
Tank Volume:5001-10000L
Drive Wheel:4×2
Seats:≤5
Horsepower:150-250hp
Engine Capacity:4-6L
Storage:Oil
Tire Type:Inner Tube
Tire Certification:ISO, CCC
Tire Design:Bias
Condition:New
Chassis Brand:Dongfeng, Dfac
Cabin:Half Row, with A/C
Cummins Engine:125kw / 170HP
Gearbox:6 Forward Gears & 1 Reverse
Drive Axle:9t
Tire:9.00-20
Tanker Load:8000L Optional 10000L 12000L
Tanker Material:Carbon Steel Optional Stainless Steel, Aluminum
Tanker Thickness:4 Mm / 5mm
Equipment:Fuel Pump Optional Flow Meter, Tanker, Refueling G
Export Markets:Global
Additional Info.
Trademark:SUNY
Packing:After Waxing by Container, RO-RO, Bulk Freighter
Standard:ISO&CCC
Origin:Hubei Suizhou
Production Capacity:500 Unit / Month
Product Description
Cummins 170hp diesel engin,6-speed,
9tons rear axle,
tanker Material:Carbon steel Q235
Optional:Stainless steel SS304 SS316
Optional :10000L fuel tanker truck
| Products Technical Specification | ||
| Product Name | Dongfeng 4*2 FuelTank Truck | |
| Chassis model | EQ1121 | |
| Fuel type | Diesel | |
| Cabin | Dongfeng153,Half row,with sleeper | |
| Emission Standard | Euro 3 | |
| Fact Cubage (L) | 8000 | |
| Whole vehicle main dimensions (mm) | Overall dimensions (L×W×H) | 7300*2470*2800 |
| Tank dimensions | 4500*2200*1400 | |
| Wheel base | 3950 | |
| Front overhang | 1250 | |
| Rear overhang | 1820 | |
| Min. ground clearance | 400 | |
| Weight data (kg) | G.V.W | 12450 |
| Curb weight (chassis) | 5445 | |
| Max payload | 8000-12000 | |
| Whole vehicle main performance | Max. speed (km/h) | 80 |
| Max. slope of climb (%) | 30 | |
| Engine | Model | B170 33 |
| Maximum power | 125kw / 170hp | |
| Number of cylinders | 6 | |
| Displacement (L) | 5900 | |
| Engine Manufacturer | Dongfeng Cummins Engine Co., Ltd. | |
| Gear box | Number of gears | 6 forward gears & 1 reverse |
| Axle | Front Load capacity (ton) | 3.6 |
| Rear Load capacity (ton) | 9 | |
| Suspension | Front | 8- Leaf spring |
| Rear | 10+8-leaf spring | |
| Steering Wheel | left/right hand drive | RHD |
| Brake system | Service brake | Air braking |
| Electric device | Rated voltage | 24V |
| Tyres & Quantity | 9.00-20 6+1 | |
| Tank Description | ||
| Tank dimensions(mm) | 4500*2200*1400 | |
| Standard configuration | Shape | Oval or Square |
| Material | Carbon steel Q235 Optional Stainless steel | |
| Thickness | 4mm Optional 4mm | |
| Single-chamber one manhole,two artesian mouth, two pipelines, Equipment, pumps,Refueling gun, flow meter, tax fuel dispenser,refueling reel (Optional all API Standard) Equipped with the specific pump to suck and discharge the oil automatically. Discharge and loading,Gravity discharge,Top loading.Optional:Bottom loading | ||
- Q: Where do I need to hit butter from the truck?
- The drive shaft, the direction bar, the vertical shaft, the I-beam, the lug, and the grease mouth. Unlike heavy loads, the butter is usually a heavy load.
- Q: Classification of freight car bridges
- Look at the head, big head is round by bridge, is the Steyr bridge, the bridge is a single small bipolar spindle bridge pickup is not very clear, generally a large cargo or tractor is 457. 485 and so on, there are 3851092 cargo.. The largest single stage bridge is the liberation of the J6 series, equipped with the 500 Bridge
- Q: Do household vans require level two maintenance?
- Only the operating vehicles need two levels of maintenance, and the family type does not belong to the operating vehicles, so there is no need to do the two level maintenance. My car is working on the team, only two households regularly submitted to the card team, the car can be completed without line!
- Q: How exactly is the tire pressure of the truck?
- Specific to each tire pressure should hit how much, the recommended value of the car factory shall prevail. This is because the tire pressure setting is mainly taking into account the weight of the body, chassis height and other vehicle factors. There is no necessary connection with what brand of tyre you use.
- Q: How can farm cars and trucks be distinguished?
- Agricultural vehicles generally include the following characteristics:Diesel engine, reliable beam. Four wheel drive with differential lock, with off-road tire tread or tire pressure and wide section, single tire, tread the shaft before and after the same, higher ground clearance, large angle, close to the longitudinal angle and the angle of departure, shorter wheelbase, wider track. Therefore, the utility model has better adaptability, flexibility and lateral stability, and is suitable for field and pasture transportation boxes.The gearbox grade more, and high - grade double transfer case. The utility model can be operated at low speed, and has the advantages of large drawbar pulling force and high speed on the road, and has better adaptability.It has mechanical and hydraulic power output device, which provides power for supporting various kinds of professional transportation auxiliary devices. Equipped with compartments for different purposes.The cab has a good view and can be operated safely and conveniently. The utility model has the advantages of simple structure, low cost and removable canvas roof. The modified ordinary truck for agricultural vehicles was converted into an agricultural special vehicle, and the power take-off and power output device or hydraulic oil pump were mounted on the gearbox as needed. Some are also equipped with electrical equipment, to provide power and monitoring system for ancillary devices.
- Q: Are light vans small or large?
- A large car refers to the total mass of 4.5t (inclusive), the number of ride (except the driver) 20 people (including 6 m) or long (inclusive) above the car. Such as ordinary buses, medium-sized trucks and large special vehicles are large cars.A large car with a front, rear, large, and yellow bottom.
- Q: Why do some small trucks directly start with the second file?
- To reduce fuel consumption, reduce the abrasion of the clutch ~ key is power than the family car, so unless pulled by a heavy start.
- Q: Can Ford F150 pickup go to town?
- Whether the pickup will be restricted or not depends on the city's traffic regulations, subject to certain standards of traffic in the city,
- Q: How many volts is the battery of a big truck?
- Truck engine power, relative to the starting current needs large, starter is 24V, the battery design is 12V, you need two sets of battery to start the engine.
- Q: What kind of brakes do all big trucks use?
- When the driver depresses the brake pedal, the gas first opened, high pressure gas storage cylinder to the relay valve. The control valve of the piston after launch, then another gas reservoirs can adoptive pneumatic valves and two rear brake pump connected. Brake push rod pump put forward by adjusting the back. The cam rotation of a cam angle is eccentric, rotating the brake shoes and brake friction to the open brake effect.
