GC258LC-8 Hydraulic Crawler Excavator
- Loading Port:
- China Main Port
- Payment Terms:
- TT OR LC
- Min Order Qty:
- -
- Supply Capability:
- 60 unit/month
OKorder Service Pledge
OKorder Financial Service
You Might Also Like
GC258LC-8 Hydraulic Crawler Excavator’s Operating Weight is 25.1t, equipped with CUMMINS 6BTAA5.9-C150 Engine, with Boom 5.85m, Arm 3.05m, Bucket 1.2m3.
GC258LC-8 Hydraulic Crawler Excavator
Technical Specifications
Engine | Travel System | |||||||||||||
Model | CUMMINS 6BTAA5.9-C150 | Travel motors | DOOSAN, Korea; Variable axial piston motor | |||||||||||
Type | Water cooling, turbocharged, empty enter-cooling | Support roller quantities | 2×10 | |||||||||||
Carrier roller quantities | 2×2 | |||||||||||||
No. of cylinder | 6 | Travel shoes | 2×51 | |||||||||||
Bore and stroke | 102mm×120mm | Travel speed | 3.6/5.5km/h | |||||||||||
Displacement | 5.9L | Drawbar pulling force | 214kN | |||||||||||
Power output | 133kW/2000rpm | Grade ability | 70% (35°) | |||||||||||
Ground clearance | 440mm | |||||||||||||
Hydraulic System | Cab & Control | |||||||||||||
Pump | KAWASAKI, Japan | Cab | All-weather, sound-suppressed Cab and equipped with a heavy, insulated Floor Mat; Front Window can be opened and slid; 6-direction adjustable Seat; LED display, Automatic monitoring, display and warning; cool & hot Air Conditioner | |||||||||||
Type | variable double–piston pump | |||||||||||||
Max. discharge flow | 480L/min | |||||||||||||
Max. discharge pressure | ||||||||||||||
Boom, arm and bucket | 32.3MPa | Control | Two hand levers and two foot pedals for travel Two hand levers for excavating and swing; Electric rotary-type engine throttle | |||||||||||
Travel circuit | 32.3MPa | |||||||||||||
Swing circuit | 25.5MPa | |||||||||||||
Control circuit | 3.5MPa | Boom, Arm & Bucket | ||||||||||||
Pilot control pump | Gear type | Boom cylinder | 130mm×90mm×1335mm | |||||||||||
Main control valve | Negative flow control | Arm cylinder | 140mm×100mm×1635mm | |||||||||||
Oil cooler | Air cooled type | Bucket cylinder | 130mm×90mm×1120mm | |||||||||||
Swing System | Refilling Capacities&lubrications | |||||||||||||
Swing motor | KAWASAKI, Japan | Fuel tank | 400L | |||||||||||
Swing motor type | Axial-piston motor | Cooling system | 14L | |||||||||||
Brake | Hydraulic oil released | Engine oil | 20.5L | |||||||||||
Parking brake | Hydraulic disc brake | Hydraulic oil tank | 200L Tank oil level | |||||||||||
Swing speed | 11.5r/min | 254L Hydraulic system | ||||||||||||
Bucket | ||||||||||||||
Type | Backhoe bucket | |||||||||||||
Bucket capacity | 1.2m3 (SAE) | |||||||||||||
Bucket width | 1278mm | |||||||||||||
Arm Type |
| |||||||||||||
A | Max. digging depth | 10170mm | ||||||||||||
B | Max. dumping height | 7150mm | ||||||||||||
C | Max. digging height | 6912mm | ||||||||||||
D | Max. vertical digging depth | 6020mm | ||||||||||||
E | Max. Depth cut for 2440m(8')Level Bottom | 6668mm | ||||||||||||
F | Max. digging distance | 10227mm | ||||||||||||
G | Max. digging radius at ground level | 10048mm | ||||||||||||
H | Min. swing radius of work equipment | 3276mm | ||||||||||||
Digging Force (ISO6015) Unit: kN | ||||||||||||||
Arm length | 3050mm | |||||||||||||
Bucket digging force | 167kN | |||||||||||||
Arm digging force | 152kN | |||||||||||||
Arm Type 3050mm | ||||||||||||||
A | Overall length | 10000mm | I | Tread | 3845mm | |||||||||
B | Ground contact length (Transportation) | 5387mm | J | Track length | 4661mm | |||||||||
C | Overall height(to top of boom) | 3130mm | K | Track gauge | 2580mm | |||||||||
D | Overall width | 3180mm | L | Track width | 3180mm | |||||||||
E | Overall height(to top of cab) | 2998mm | M | Shoe width | 600mm | |||||||||
F | Counter weight ground clearance | 1067mm | O | Bonnet height | 2365mm | |||||||||
G | Ground clearance | 440mm | P | Revolving frame width | 2700mm | |||||||||
H | Tail swing radius | 3040mm | Q | Distance from swivel center to tail | 3010mm | |||||||||
| ||||||||||||||
Operating Weight and Ground Pressure | ||||||||||||||
Operating weight includes basic machine (with boom 5.85m, arm 3.05m, and bucket 1.2m3) | ||||||||||||||
Shoe width | 600mm | |||||||||||||
Overall width | 3180mm | |||||||||||||
Ground pressure | 49KPa | |||||||||||||
Operating weight | 25100kg |
- Q:What is the distance between the rigger and the excavator?
- Distances between riggers and excavators vary. It could be a couple of feet or thousands of miles.
- Q:What does it mean to walk an excavator and how do u do it?
- Only a guess here but it may refer to using the bucket and arm to pull or push the machine along without engaging the tracks or wheels.
- Q:Are there any differences between backhoe and crawler hydraulic excavators?
- These are two completely different conceptsBackhoe bucket is a form of installation, is our common kind of excavator bucket, bucket shovel is to turn over. Generally only in the 100 tons or more models will be equipped with shovelAccording to this standard, there are two forms of spade (backhoe and backhoe)Hydraulic crawler excavator means that the walking gear is in the form of caterpillar tracks, according to which there are (wheeled, tracked)
- Q:What is the difference between a loader and an excavator?
- Excavator, also called excavating machinery, is a kind of earthmoving machine that uses bucket to excavate material that is higher than or lower than the machine surface and is loaded into transportation vehicle or unloaded to the stacker. Excavators are mainly made of soil, coal, sediment, and soil and rocks that have been pre - loosened. From the development of engineering machinery in recent years, the development of excavator is relatively fast, excavator has become one of the most important construction machinery in engineering construction. The three most important parameters of excavator are operation weight (quality), engine power and bucket bucket capacity.Both are earthwork operations, excavators (commonly known as hook machine) bucket can be below the horizontal line. The bucket of the loader can only be above the horizontal line. The difference is that the two uses are different. Sometimes they can substitute for each other. There are many types. Under normal circumstances, a large number of materials on the horizontal surface are installed in the loader, and the utility model has the advantages of large bucket capacity, flexible movement, high loading efficiency and good economy. But the loading and excavating of materials under the horizontal plane can only be done by excavators.
- Q:I need to purchase jcb paint to touch up my excavator asap and I cannot find any information on the jcb color yellow. It is very important that i find the precise color and i would be grateful to anyone who can offer any information on this. Thanks in advance
- Find a local Carquest store that carries paint. They might have a formula for JCB yellow. If not then you will probably need to bring a painted piece in for them to match to.
- Q:A company that buys excavators from an subcontractor knows by experience that certain proportion of the excavators will be faulty. 3 types of errors occurs,denoting by errortype a,b and c. Probability that errortype a occurs on a random selected excavator is 6%. For b it is 2% and for c 5%. The errors occurs independently of each other. a) Calculate the probability that a randomly chosen excavator has atleast 1 of the 3 errors b) Assume that one excavatoris shown to have both error a and b. What is probability that it also have error c ? Ans: a)0.875 b)5.0
- a) 1 - (0.06 + 0.02 + 0.05) = 1 - 0.13 = 0.87............. NOT 0.875 b) 0.05................................. NOT 5.0 --------------------------------------...
- Q:My family own a large landscaping and irrigation company and were thinking of buying a mini excavator for removing trees and planting bigger trees i.e. palms and such. We also install irrigation up to 4 inches of Pvc pipe and repair all kinds. Also French drains. If anyone has anything else I would love to know your opinions! All comments are welcome negative and positive. Thanks!
- I don't believe that You or any member of Your family owns a Landscaping or Irrigation company because if You did You would already know what You need.
- Q:Which expert knows the excavator of this brand of Singway?
- The Sinoway excavator you saw should be the excavator it bought, attached to its company's advertising.
- Q:Hi does anyone knows how is a wheeled excavator steered? Is it a mechanical steering like other wheel loaders. Seems impossible because the excavator cab can do 180 about the undercarriage. I thought it must be hydraulically operated or skid steered, but my CAD teacher asked it to mechanically couple the wheels with the steering wheel. Haven't been able to figure out as to how to do it yet. Any suggestions?
- Often times they articulate in the middle. In other words the vehicle is actually 2 half's. Each half joined in the middle,hydraulics actuating the articulation, thereby steering the vehicle.
- Q:Attentions of excavator operation
- First, when the downhill hand door frameExcavator super off-road capabilities, we all know. With the combination of the crawler and the working device, the excavator can climb up the steep slope, and also can slide downhill easily. There is a danger of being easily ignored the situation, is the excavator in the downhill or is under the trailer, as the body forward, many drivers will push the left handedness of the front windshield or door, right operating excavator. At this point, if the door is open and unlocked, the door is closed because it is gravity, and it is usually very powerful. Hand on the doorframe will be clamped. The consequences are serious.Excavator downhillTherefore, when the excavator is working, the door of the excavator cab is closed with a lock, and a lock is opened, and the door must be locked whether the door is open or closed. The driver tried not to walk the door frame.Two, walk high armMany beginners or apprentices feel that the boom of the excavator is the highest. The bucket is fully opened and the bucket is in the air, so that the vision will be better when walking, and if so, it will be cool to walk and spin at the same time. It is very dangerous to walk in this way. As the working device is held high, the center of gravity is high and the ground is slightly uneven.Hold your arms high when you walkSo walking and operation must not be cool, look at the foot of the road is the most important.
