Led Lights For Homes 2 Years Warranty 9w To 100w With Ce Rohs c-Tick Approved
Description
Wide beam angle 300degree bulb lamps.
a, SMD3014 with low heat sink
b, High performance 6w/590lm.9w/870lm
c, UL,ErP,CE,PSE
Product features:
Power Consumption: 6w 360degree lighting bulbs
Voltage: AC 100V-277V
Color Temperature: 2700K-6500K
Luminous Flux: 590lm
Dimension:60x118MM
Light Source: Epistar SMD3014
Certification: CE RoHS,UL,SAA,ErP,PSE,
Warranty: 3years
Dimmable available
Totally a replacement of 40w incandescent bulb.
Feature
The DLS 9W LED bulb light is designed and manufactured to replace the 60-75W incandescent /Halogen bulb and 19W CFL, the superior SMD LED solution and purity aluminium material makes the luminous efficacy high to 89LM/W, it is of excellently heat managed by conjoint structure which maintains the LED working temperature in a comfortable condition.
Excellent heat management
SMD LED solution
Superior high quality bulb
Environmental friendly
Energy saving perfect replacement for 60-75W incandescent bulb
Parameter
Electrical and optical parameter | |
Power dissipation | 9.5W |
Luminous flux | 850Lm±5% |
Color temperature | 2700-5800K |
Luminous Efficacy | 89Lm/W |
Color rending index | 82 |
Lighting source | 2835 SMD LED |
AC input voltage | AC85-265V |
Power factor | 0.9 |
Driver efficacy | 90% |
Beam angle | 150° |
Weight | 112g |
Quality guarantee | 3 years |
Lifespan | 40,000hrs |
FAQ
Q: Are you a factory or trading company?
We are a state-owned corporation in China,dealing with various kinds of building materials.We have our holding subsidiaries.
Q: Where is your factory located? How can I visit there?
Our factory is located all around China.
Q: Can I get some samples?
Sample is free, customer only pay freight for the first time.
Q: Delivery?
10-30days. (5-15 containers)
Any question,feel free to contact us.
- Q: LED bulb lamp drive power electrical connection, will delay a few seconds before the lamp light, and power creaks, who know what it is!
- How many seconds delay? It won't take so long. How many bulbs do you usually soak in 0.5 seconds? A squeaky noise is usually a transformer or inductance whistle, and at least it shows a poor manufacturing process.
- Q: What's the reason for the LED bulb strobe?
- If this resonant characteristic causes the input current to fall below the TRIAC sustaining current, the TRIAC will turn off. After a short delay, the TRIAC usually switches on and fires the same resonance. In the 1.5 cycle of the input power waveform, this series of events may be repeated several times to form visible LED flashes. To cope with this problem, a key requirement of TRIAC dimming is that the input capacitance of the EMI filter is very low and that the capacitor is decoupled through the TRIAC and the winding impedance. According to the formula, if the capacitance of the dimming module is reduced, the resistance of the resonant circuit can be increased, and the oscillation is suppressed in principle, and the desired circuit work is resumed.
- Q: How to identify Ic constant current LED bulb?
- Hello, LED market is now very confused, this problem is the use of LED lamps of the users are more concerned about the problem, the so-called IC constant current drive power refers to the LED lamp (commonly known as the transformer) with a constant stream of multifunctional IC chip, the IC is generally 5-8 feet (depending on the model and decision scheme), role is to ensure that the current through LED lamp is controlled in a relatively constant parameter, ensure the long-term stability of LED lamp work at constant current. When the input or output voltage is changed, the current through LED remains constant, so the constant current IC of the LED light stability and service life is directly related to the IC also includes internal short circuit protection, overtemperature protection function of open protection etc.
- Q: What does the LED bulb patch mean?
- According to different applications, different size, cooling scheme and luminous effect of.LED packaging forms. At present, according to the classification of LED package are mainly Lamp-LED, TOP-LED, Side-LED, SMD-LED, High-Power-LED, Flip Chip-LED Lamp-LED (vertical LED) emerged in the early Lamp-LED is in line LED, it adopts the form of sealing packaging. The potting process is the first injection of liquid epoxy resin in LED molding cavity, and then insert the pressure LED bracket welding, in the oven make epoxy resin after curing, the LED from the cavity from the molding. Due to the relatively simple fabrication process, low cost, have a higher market share. (SMD-LED surface mount LED) patch LED is pasted on the surface of a wiring board, suitable for SMT processing, can be reflow, a good solution to the brightness, perspective, smoothness, consistency, reliability and other issues, the The lighter PCB plate and a reflecting layer material, improved to remove the carbon steel pin dip LED heavier, the display of epoxy resin less reflective layer needs to fill, to reduce the size, reduce the weight. In this way, the surface mount LED can easily reduce the weight of the final product in half, make the application more perfect.
- Q: Are there any differences between negative ion bulb and LED bulb?
- Negative ions should belong to traditional lighting technology, LED is the latest lighting technology
- Q: Led what's the flash of the bulb?
- There are several cases of flashing lights:There is one to three flashes when the switch is switched off. This is due to an incomplete discharge of the electrolyte in the power supply.The power supply is flashing fast. This is the quality of the power supply problems, there are many specific reasons.It is found that the design of the power supply is related to the structural design of the lamp due to the insufficient margin of the power supply and the increase of temperature!The general power supply too much heat to stimulate the overheating protection function itself with the power supply, power supply is a protection device, when the heat is too large, may cause it has an adverse effect on power and light, power will take the initiative to make the lamp power, rest, fully dissipated heat later. Bright.
- Q: LED bulb is broken. The luminous patch is not bad. Can it be made into USB lamp?
- LED bulb is broken. The luminous patch is not bad. It can be made into USB lamp.LED bulb is usually a series of LED series, and then parallel, generally about 12V.Single chip LED generally rated voltage at 3.0V~3.6V, USB, output voltage of about 5.0V.Look at the LED in the LED bulb. Several LED are connected in series. Several groups are connected together, and then the voltage is estimated.Then the power of the bulb is divided by the voltage of the LED bulb to calculate the required current.Select the appropriate LED drive circuit. The average USB output current of the computer is only 100mA~500mA. The power is not enough to make the LED light to normal brightness, or it may damage the USB interface. It is better to use the USB charger interface.Light emitting diodes, referred to as LED. Made from compounds containing gallium (Ga), arsenic (As), phosphorus (P), nitrogen (N) and so on.
- Q: Choose which light bulb LED bulb is the healthiest
- For home use, you can select LED bulb below 8W, with a color temperature below 3500K
- Q: Detailed description of LED bulb lamp
- Healthy LED is a green light source. The LED lamp is driven by DC without flicker. Without infrared and ultraviolet components, without radiation pollution, it has high color rendering and has a strong luminous directionality, good dimming performance and no visual error when the color temperature changes
- Q: What does "A19" mean in LED A19 bulb?
- I'm studying too! There's a problem for everyone to discuss
