Product Description:

Long-Distance Coach Bus                      DD6125K04

□Dynamic, boosting, fashionable appearance full of personality style

Healthy, fresh, elegant and natural interior trimming

Stable, economic, reliable and durable key components

Professional, advanced, accumulated technologies

Flagship style leading the wave of the future



Engine


DD6125K04

Model

YC6G270-30

Type

6 cylinder in line, 4-stroke, water cooling, intercooler, turbo diesel engine

DisplacementL

7.803

Max power (Kw/rpm)

199/2500

Max torque  (N.m/rpm)

1080/1400-1600

Fuel tank (L)

160×2



Chassis

Model

DD6125K04

Clutch

Φ430 single leaf, dry

Transmission

Mechanical MT with synchronizer

Rear Axle

Integral stamping and welding type with low-noise gear

Suspension system

Leaf spring with telescopic shock absorber and stabilizing bar.

Tire

295/80R22.5(Optional : 12R22.5)

Rim

8.25X22.5

Brake system

Drum, double circuit air braking, energy storage spring air cut-off actuating on rear axle

Steering system

Integral hydraulic power steering

Luggage cabin (m³)

7



Dimensionmm


DD6125K04

Length

11950

Width

2500

Height

3630

Wheelbase

6200

TreadF/R

2023/1834

Approach/Departure angle(°)

9/9

Min ground clearance

253

Internal height

2050



Main Body Equipments


DD6125K04

Passenger door

Single or double door, outward swing pneumatic type

Window

Laminated front window shield, tempered glasses for other windows

A/C

Dependent A/C

Heating system

Water heating system

Service Facilities

Optional: video & audio, curtain, clock, reading lamp, drinking water machine, tire cover, etc



Weightkg


DD6125K04

Gross weight

17000

Curb weight

13000

Number of seat

5551 with double doors

Seat layout

2+2



Performance


DD6125K04

Max speedkm/h

110

Min turning diameterm

20

Max grade ability%

24

Fuel consumptionL/100km

28 (under given condition)
