Product Description:
MPB has the features of city, intercity bus and coach and integrates the comfort, large luggage cabin and fashionable appearance of coach and large capacity of city bus, which is very suitable for the use between urban and suburban areas, of regular bus and normal transportation.
Engine
| DD6119K63 | DD6119K64 | DD6119K65 |
Model | YC6G240-30(Euro Ⅲ) | SC8DK230Q3(Euro Ⅲ) | WP10.240(Euro Ⅲ) |
Type | 6 cylinder in line, 4-stroke, water cooling, intercooler, turbo diesel engine |
Displacement（L） | 7.8 | 8.27 | 9.726 |
Max torque (N.m/rpm) | 950/1200-1500 | 830/1400 | 1000/1200-1600 |
Max power (Kw/rpm) | 177/2200 | 170/2200 | 175/2200 |
Fuel tank (L) | 200（2×130L for thorough luggage cabin） |
Chassis
| DD6119K63/K64/K65 |
Model | 6119K |
Transmission | Mechanical MT |
Rear axle | Integral stamping and welding type |
Main reduction ratio | 5.571 |
Suspension system | Leaf spring with stabilizing bar and telescopic shock absorber |
Tire | 11.00R20/ 11.00-20 |
Steering system | Integral hydraulic power steering |
Service brake | Drum |
Parking brake | Energy storage spring actuating on rear axle |
Others | China made ABS, automatic slack adjustment bar |
Dimension（mm）
| DD6119K63/K64/K65 |
Length | 11420 |
Width | 2545 |
Height | 3430/3555 |
Wheelbase | 5700 |
Tread（F/R） | 2040/1860 |
Approach/Departure angle（°） | 9/9 |
Min ground clearance | 240 |
Internal height | 2160/2090(3+2) |
One step height from ground | 400 |
Main Body Equipments
| DD6119K63/K64/K65 |
Passenger door | Single leaf outward swing pneumatic type (optional: 2 doors) |
Window | Hyperboloid front window shield, tempered glasses, sliding window (optional: bonded type) |
A/C | Optional |
Heating system | Water heating defroster（optional: water heating system） |
Service Facilities | Optional: video & audio, curtain, clock, reading lamp, drinking water machine, tire cover, etc |
Others | Optional: thorough luggage cabin, separated luggage cabin, aluminum/steel skirt door |
Weight（kg）
| DD6119K63/K64/K65 |
Gross weight | 16000 |
Curb weight | 11500（12200） |
Number of seat | 24-61，59，51 |
Seat layout | 2+2，(with middle door: 47+1, if 3+2, 1-door: 60+1，2 -door: 58+1) |
Performance
| DD6119K63/K64/K65 |
Max speed（km/h） | 90 |
Min turning diameter（m） | ≤24 |
Max grade ability（%） | ≥20 |
Fuel consumption（L/100km） | 26 (under given condition) |
