Product Description:

Long-Distance Coach Bus                        DD6119K(MPB)

MPB has the features of city, intercity bus and coach and integrates the comfort, large luggage cabin and fashionable appearance of coach and large capacity of city bus, which is very suitable for the use between urban and suburban areas, of regular bus and normal transportation.



Engine


DD6119K63

DD6119K64

DD6119K65

Model

YC6G240-30(Euro )

SC8DK230Q3(Euro )

WP10.240(Euro )

Type

6 cylinder in line, 4-stroke, water cooling, intercooler, turbo diesel engine

DisplacementL

7.8

8.27

9.726

Max torque  (N.m/rpm)

950/1200-1500

830/1400

1000/1200-1600

Max power (Kw/rpm)

177/2200

170/2200

175/2200

Fuel tank (L)

2002×130L for thorough luggage cabin



Chassis


DD6119K63/K64/K65

Model

6119K

Transmission

Mechanical MT

Rear axle

Integral stamping and welding type

Main reduction ratio

5.571

Suspension system

Leaf spring with stabilizing bar and telescopic shock absorber

Tire

11.00R20/ 11.00-20

Steering system

Integral hydraulic power steering

Service brake

Drum

Parking brake

Energy storage spring actuating on rear axle

Others

China made ABS, automatic slack adjustment bar





Dimensionmm


DD6119K63/K64/K65

Length

11420

Width

2545

Height

3430/3555

Wheelbase

5700

TreadF/R

2040/1860

Approach/Departure angle(°)

9/9

Min ground clearance

240

Internal height

2160/2090(3+2)

One step height from ground

400



Main Body Equipments


DD6119K63/K64/K65

Passenger door

Single leaf outward swing pneumatic type (optional: 2 doors)

Window

Hyperboloid front window shield, tempered glasses, sliding window (optional: bonded type)

A/C

Optional

Heating system

Water heating defrosteroptional: water heating system

Service Facilities

Optional: video & audio, curtain, clock, reading lamp, drinking water machine, tire cover, etc

Others

Optional: thorough luggage cabin, separated luggage cabin, aluminum/steel skirt door



Weightkg


DD6119K63/K64/K65

Gross weight

16000

Curb weight

1150012200

Number of seat

24-615951

Seat layout

2+2(with middle door: 47+1, if 3+2, 1-door:  60+12 -door: 58+1)



Performance


DD6119K63/K64/K65

Max speedkm/h

90

Min turning diameterm

24

Max grade ability%

20

Fuel consumptionL/100km

26 (under given condition)
