Smooth&Textured ASTM PE/EVA/ECB Geomembrane

Smooth&Textured ASTM PE/EVA/ECB Geomembrane

Ref Price:
$2.10 / m² get latest price
Loading Port:
Qingdao
Payment Terms:
TT or L/C
Min Order Qty:
10000 m²
Supply Capability:
300000 m²/month

Add to My Favorites

Follow us:


OKorder Service Pledge

Quality Product, Order Online Tracking, Timely Delivery

OKorder Financial Service

Credit Rating, Credit Services, Credit Purchasing

Smooth&Textured ASTM PE/EVA/ECB Geomembrane

Iterm

Technical Data

Thickness mm

0.75

1

1.25

1.5

2

2.5

3

Density g/cm3

0.940

0.940

0.940

0.940

0.940

0.940

0.940

Yield Strength N/mm

11

15

18

22

29

37

44

Break Strength N/mm

20

27

33

40

53

67

80

Yield Elongation %

12

12

12

12

12

12

12

Break Elongation %

700

700

700

700

700

700

700

Tear Resistance N

93

125

160

190

250

315

375

Puncture Resistance N

240

320

400

480

640

800

960

Carbon Black Content %

2.0-3.0

2.0-3.0

2.0-3.0

2.0-3.0

2.0-3.0

2.0-3.0

2.0-3.0

Standard OIT min

100

100

100

100

100

100

100

High Pressure OIT min

400

400

400

400

400

400

400

Oven Aging at 85°C %

55

55

55

55

55

55

55

UV Resistance %

50

50

50

50

50

50

50

Smooth&Textured ASTM PE/EVA/ECB Geomembrane

Smooth&Textured ASTM PE/EVA/ECB Geomembrane

Smooth&Textured ASTM PE/EVA/ECB Geomembrane

FQA:

- Q: What can we do for the special customer?

  A: Provide custom made service with customer's drawing; We make sure to provide you with the best solutions for your individual case. Whether standard items or non-standard items.

- Q: What can we supply?

  A: We provide high levels of communication from start to finish.

- Q: What is our advantage?

  A: Top Cemented Carbide has extensive business experience, Fast delivery and high quality.


Q:What is made of stretch film?
Stretch film material: Low density polyethylene (LDPE), linear low density polyethylene (LLDPE), high density polyethylene (HDPE).
Q:the higher the carbon black content in Landfill HDPE geomembrane, the better.
If it contains little carbon black, it will have poor UV resistance and aging resistance performance, so is the case when it contains too much. So it is not the higher the better. Usually the carbon black content is between 2% -3%. carbon black content can be adjusted by adding into geomembrane black masterbatch.
Q:Can geomembranes be used in rooftop gardens and green roofs?
Yes, geomembranes can be used in rooftop gardens and green roofs. Geomembranes are impermeable barriers that prevent water leakage and can be used as liners to contain and protect the underlying structure of rooftop gardens and green roofs. They help in retaining moisture, preventing root penetration, and ensuring proper drainage, making them an effective solution for these types of applications.
Q:Brief introduction of geomembrane
The geomembrane is a kind of waterproof barrier material, which takes the high-molecular polymer as the basic material. Mainly divided into: Low density polyethylene (LDPE) geomembrane, high density polyethylene (HDPE) geomembrane and EVA geomembrane. 1, complete in specifications of width and thickness. 2 has excellent resistance to environmental stress cracking and excellent resistance to chemical corrosion. 3, excellent resistance to chemical corrosion. 4 has a larger using temperature range and a longer service life. 5, used in the refuse landfill, tailings storage yard, channel seepage-proofing, dam seepage-proofing and subway projects, etc.. Physical mechanical properties of geomembrane Varieties index item LDPE geomembrane HDPE geomembrane EVA ordinary type environment friendly type tensile?strength (vertical and horizontal) (MPa) ≥14 ≥17 ≥25 ≥18 breaking elongation rate (vertical and horizontal) (%) ≥400 ≥400 ≥550 right angle tear strength vertical and horizontal) (N/mm) ≥50 ≥80 ≥110 ≥90 water vapor penetration coefficiency (g.cm/cm.s.pa) ) ≤1.0x10-16 ≤1.0x10-16 ≤1.0x10-16 ≤1.0x10-16 using temperature range +70℃~-70℃ +70℃~-70℃ +70℃~-70℃ +70℃~-70℃ environmental stress cracking resistance (F20.H) - - ≥1500 - 200℃ oxidation induction time (min) ) - - ≥20 -
Q:Does the lower geotextile of composite geomembrane need seaming?
Yes, but the operation is more troublesome.
Q:Application of polyethylene geomembrane.
Sewage treatment plants, sea cucumber slope protection, chemical reaction pool: Chemical plants, roof garden anti-seepage, vertical wall: Seepage intensification, slope protection, oil refineries, irrigation systems anti seepage, polyethylene geomembrane suitable for transport facilities, sedimentation tank lining. 4, tailings seepage and other backing; as rivers, lakes and reservoirs dam seepage, water storage pond, power plants regulation pool, sedimentation tanks, industrial, drainage of seepage, tank seepage, ponds, factory farming pool, dissolved pool, water tank, slope protection, sewers, green roofs: Artificial lake. 8, leaking proof 6, polyethylene geomembrane for Salt: Road base reinforcement, polyethylene geomembrane for aquaculture industry, ashery. Saltworks crystalline pool, golf course water bottom. 9, heap leaching pool 1: Washing pool, prawn ponds lining. 3, reservoir, polyethylene geomembrane for agriculture, strengthening, building underground engineering, polyethylene geomembrane for municipal projects. 5, polyethylene geomembrane for mining, salt film, culverts impermeable, sanitation. 7: Reservoir: such as refuse landfill polyethylene geomembrane is suitable for gardening,storage yard, secondary lining etc., solid hospital wastes, green lawn waterproof tide like polyethylene geomembrane for water, polyethylene geomembrane for environmental protection.
Q:What are the advantages of using geomembranes in industrial wastewater treatment?
There are several advantages of using geomembranes in industrial wastewater treatment. Firstly, geomembranes act as a barrier, preventing the contamination of groundwater and soil by containing the wastewater within the treatment system. This helps in protecting the environment and ensuring compliance with environmental regulations. Secondly, geomembranes are highly durable and resistant to chemical degradation, making them suitable for handling various types of industrial wastewater. They have excellent resistance to corrosion, which is particularly important in industries where highly corrosive substances are present. Furthermore, geomembranes are flexible and can be installed in different configurations and shapes to suit the specific requirements of the wastewater treatment system. This flexibility allows for customization and optimization of the treatment process, leading to improved efficiency and cost-effectiveness. Additionally, using geomembranes can minimize the need for excavation and construction of concrete structures, reducing both the time and cost involved in setting up the wastewater treatment facility. They can be installed quickly and easily, making them a convenient choice for industries that require fast and efficient wastewater management solutions. Overall, the use of geomembranes in industrial wastewater treatment offers advantages such as environmental protection, chemical resistance, flexibility in design, and cost savings, making them a preferred choice for many industries.
Q:Municipal two cloth a film composite geomembrane quota how set
You are not required composite film, I am a professional production of geotextile materials
Q:What are the technical parameters of seepage-proof geomembranes?
serial number item indicator common environmental protection 1 thickness mm 0.2 to 4 2 width m 2.5 to 8 3 tensile strength (vertically and horizontally) MPa≥17 ≥25 4 breaking elongation rate (vertically and horizontally) % ≥450 ≥550 5 angle tear strength N/mm ≥80 ≥110 6 carbon black content % 2.0 to 3.0 2.0 to 3.0 7 resistance to environment stress cracking F20   ≥1500 8 low-temperature impact in -70℃ approved 9 oxidative inductive time in 200℃   ≥20
Q:Is the new crystal steel door film expensive?
It is not expensive. ① , new/ crystal steel door film/ special film for cabinets/ frontal adhesive/ wooden, the price is 8 yuan. ② new/ crystal steel doors film/ cabinet glass door self-adhesive film, the price is more than 9 yuan.
"Golden Lion" has advanced production equipment and technology and testing equipment. Our company is a large-scale backbone enterprise with geosynthetic production, scientific research, sales and development. We have 20 sets of the most advanced digital computer controlled production lines in the world, to produce short fiber, filament needle-punched geotextile, geomembrane, composite geomembrane, EVA, HDPE, LDPE waterproofing sheet, single, two-way plastics geogrid.

1. Manufacturer Overview

Location Taian City,Shandong Province,China
Year Established 2003
Annual Output Value Above US$100 Million
Main Markets Africa, North America, Eastern Europe, South Asia, Western Europe
Company Certifications ISO9001;IS014001 Certificate

2. Manufacturer Certificates

a) Certification Name
Range
Reference
Validity Period

3. Manufacturer Capability

a)Trade Capacity
Nearest Port Qingdao Port;Tianjing Port;Shanghai Port
Export Percentage
No.of Employees in Trade Department 21-30 People
Language Spoken: English; Chinese;
b)Factory Information
Factory Size: 10,000-30,000 square meters
No. of Production Lines Above 10
Contract Manufacturing Geotechnical Material (Geogrid,Fiberglass/Polyester Geogrid;Geocell;Geonet and Geomat;Plastic Safety Fence);Plastics products;Rubber products;Geotextile;Carpet;Compound geomembrane
Product Price Range Average
