HZS240 Concrete Batching Plant / ISO & CE

Ref Price:
Loading Port:
Qingdao
Payment Terms:
TT OR LC
Min Order Qty:
1 unit
Supply Capability:
5 unit/month

OKorder Service Pledge

Quality Product

Order On-line Tracking

Timely Delivery

OKorder Service Pledge

Credit Rating

Credit Services

Credit Purchasing

Share to:

Product Description:

The product is widely used in key projects like various highways, railroads, high-speed railways, airports, ports, bridges, and hydropower stations, as well as commercial concrete mixing station, real estate, and municipal construction. With constantly increasing investment in technological innovation, the company has achieved great achievements and been recognized as “Provincial Enterprise Technology Center” in 2008. The company has 4 research department respectively specializing in mixing, transportation, conveying, and automation.



Concrete mixing plant HLS240

Theoretical productivity  240m3/h

Mixer model       JS4000

Mixer nomination capacity    4000L

Mixing largest aggregate       150mm

Mixing motor power 2x55kw

Aggregate lifting belt motor power    45kw

Aggregate conveying belt width 1000mm

Aggregate lifting belt conveying capacity 800t/h

Aggregate batcher    PL6400

Aggregate bin capacity   4x25m3/Ground storage type

Aggregate batching capacity 6400L

Aggregate types 4

Powder bin capacity 100/200t(optional)

Screw conveyor  80t/h(Optional air duct conveying system)

Aggregate measuring precision   ±2%

Powder measuring precision ±1%

Water measuring precision    ±1%

Additive measuring precision       ±1%

Discharging height   3.8m

Power    300kw(without screw conveyor)

Weight    100t(without screw conveyor and cement bin)




Send a message to us:

Remaining: 4000 characters

- Self introduction

- Required specifications

- Inquire about price/MOQ

Q:What are the advantages of HZS series of concrete mixing stations
HZS75 concrete batching plant investment amount, less occupied area is small, the use of equipment, maintenance easy, can be equipped with high performance of independent control room, make the equipment operation convenient and safe, and in the batching machine also can produce high quality under the condition of accurate measurement of concrete. This type of mixing station under our positive study also used the green environmental protection design, the construction of a possible pollution under control, rather than the old way of construction and transportation pollution, nature is winning.
Q:What is the concept of on-site concrete mixer station
Concrete mixing station is mainly composed of mixing console, materials weighing system, material conveying system, material storage system and control system of large system and other ancillary facilities. Action: concrete mixing plant is used to concentrate the mixing of concrete, also called concrete precast. Because its mechanization, high degree of automation, productivity is high, and can guarantee the quality of concrete and cement, commonly used in concrete, long duration and site of quantities focus of large and medium-sized water conservancy, electric power, Bridges and other projects. Centralized with the development of municipal construction, stirring, provide commercial concrete mixing station has great advantages, and thus get rapid development, and to promote concrete pumping construction, the mixing, transportation, casting machinery joint operation to create the conditions. Basic introduction: concrete mixing station is mainly composed of mixing console, materials weighing system, material conveying system, material storage system and control system of large system and other ancillary facilities.
Q:How much concrete is produced by the js1000 type of the concrete mixing station
According to the national standard, 1 cubic host is the JS1000, the general theoretical productivity of the standard test concrete is not less than 50 cubic meters per hour. But the actual situation is fully automatic, normally can be above 40 cubic meters. The cement productivity would be low by hand.
Q:What kind of sand is needed for a concrete mixer
Which have so many requirements, sand silt content not too many, too many big rocks, soil, too much, artificial sand and river sand can, had better not use weathering sand, not according to the standard to which have the standard, is to see the skill of your lab
Q:How long does it take to build a concrete mixer station?
Normally, between one and three weeks. Plan the main points of the stirring station Venue: single 2m3, 3m3, the equipment occupies an area of about 21mx51m. Add in the yard, parking lot, road, office building, repair shop, recycling pool and so on, usually need the site 40mx80m (the land of 5 acres). 2m3 and 3m3 stations usually require 60mx80m (7.5 acres). If the location is more complex, the layout of the equipment should be based on the utilization of the site. To reduce the cost of future operations, it is suggested that there be a river at the edge of the site so that it can be used to carry sand stones. Distance should consider the best range of concrete delivery vehicles, not too far away from the main site, but also for future development. Optional: choose according to the expected amount of concrete. In a year of 300 working days, eight hours a day, the actual efficiency is lower than the nominal value given the various factors that are affected. Considering the requirement of the equipment for regular maintenance and maintenance, and the requirement of the high demand in some period, it is suggested that the equipment should be purchased. In some areas, the construction of new concrete and concrete stations must be at least two.
Q:What are the ingredients for the concrete mixing stations?
It is the raw materials for the concrete mixers, the sand, stone, cement, fly ash, mineral powder, various admixtures, water, basically these seven raw materials.
Q:Classification of concrete mixing stations
Commercial concrete mixing station: single/double HZS90 concrete mixing station, single/double hzss120 concrete mixing station, single/double hzss240 concrete mixing station, single/double hzss240 concrete mixing station. Engineering concrete mixing station: HZS75 concrete mixing station, HZS60 concrete mixing station, HZS50 concrete mixing station, HZS35 concrete mixing station, HZS25 concrete mixing station. Mobile concrete mixer station
Q:The main components of a mixing station
The conveying system of materials is made up of three parts. Aggregate conveying; There are two ways of conveyance and belt conveyance. The advantage of hopper promotion is that the area is small and the structure is simple. The advantage of belt transport is that the transport is large, efficient and low. The belt conveyor mainly applies to the mixing stations that have aggregate storage, thereby increasing the productivity of the mixing stations. Powder conveying; The powder used in concrete is mainly cement, fly ash and mineral powder. The most commonly used powder conveyors are conveyors of screw conveyors, and the large mixing buildings are carried by pneumatic conveyer and scraper. The advantages of screw transport are simple structure, low cost and reliable use. Liquid transport mainly refers to water and liquid admixtures, which are delivered separately by water pumps
Q:Concrete mixstations belong to no special equipment
Is not mixing station is places or facilities, equipment, for whether the equipment belongs to the special equipment to check the catalog of special equipment, included in the directory is the special equipment, is not included.
Q:Does the concrete mixing station name have the name of the businessman concrete
Yes, concrete means artificial stone, which can be understood as the simple writing of concrete, which means concrete for commercial concrete. This is the name of the blender
