Introduction

In the FRP .with high tensile strength, the fiberglass plays the role of reinforcement whiles the wear-resistance and pressure –resistance synthetic resin is used for bonding the fiber as the basic materials. Putting together, they commonly play the role of being in finished form and load carrier.

Feature

The wall structure of the FRP pipe is normally consisting of two parts:

Structure layer: make the continuous glass fiber woven of which is cross winded according to the design angle as the reinforcing frame. Make the synthetic resin as the bonding basic materials. Among them, the weight of fiberglass occupied about 65-70% weight of resin about 30-35%. In order to strengthen the structural stiffness, the resin and silicon sand paste could be added in the middle layer of fiberglass filament winding layer.

Specification

u  2.5” Precision injected threads opening available in 8”~16” diameter tanks

u  4” precision injected threads opening available in 18”~36” diameter tanks

u  6” Flange opening available in 42”~80” diameter tanks

u  8”~18” diameter tanks available top opening only

u  21”~80” diameter tanks available top and bottom opening

u  Tripod bases available in sizes of 21”~80” diameter tanks

u  Optional side opening is available

Materials

u  The liner layer is PE (polyethylene) materials for 8”~36” diameter tanks

u  The liner layer is FRP (fiber reinforced plastic) for 42”~80” diameter tanks

Working condition

u  Operating pressure: 0.6Mpa (100psi)

u  Bursting Pressure:  1.8Mpa (300psi)

u  Testing pressure:    0.9Mpa (150psi)

u  Working temperature: below 50 centigrade

Application

Pre RO, Ion Exchange, Water softener, water filtration, House hold water filtration, Food and beverage, water storage

Opening

u  2.5”~4” UN threads ABS opening;

u  6” Flange FRP;

u  other customized manway and side flange

Advantage

u  Good corrosion resistance

u  High mechanical strength at low specific gravity

u  Good resistance to weathering

u  Light weight

u  Good insulating qualities

u  Provide less maintenance & repairs down time

u  Easy installation

FAQ

1. Do You Arrange Shipment For The Machines?

Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.

2.      What's the guarantee, in case the water tank breaks down?

The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts will be replaced for free if the problems are caused by quality fault.

3. How about the documents after shipment?

After shipment, we ll send all original documents to you by DHL, including Packing List.Commercial Invoice, B/L, and other certificates as required by clients.
