Product Description:

Product Description:

General introduction of Push-on Joint T Type Ductile Iron Pipe

•Material : Ductile Cast Iron

•Size Range : DN 80mm to DN 2000mm

•Unit Effective Length : 6m or 5.7m

•Manufacture Standard: ISO 2531:1998/ EN 545:2006/EN 598:2007

•Annual capacity : 300,000 tons

•Coating Exterior: Zinc 130g/m2 according to ISO 8179-1 and bitumen coating 70 microns.

•Cement Interior: Portland Cement/ High Alumina Cement/ Sulphate Resisting Cement Lining according to ISO 4179

•Special requirements on external coating and internal lining can be applied

•We also provide accessories such as SBR/EPDM rubber gaskets, lubricant paste, pipe caps, PE sleeves, etc.

Features of Ductile Iron Pipes:

.            Ductile Iron Pipe offers proven reliability and the quality.

.            It is quick and easy installation.

.            The ductile iron pipe has high pressure capability.

Application:

Used for water and sewer lines.

Specification of Push on Joint T Type Ductile Iron Pipe K9:

Standard wall thickness of Push on Joint T Type Ductile Iron Pipe K9

Nominal Diameter

Wall Thickness(mm)

DN(mm)

Pipe

Fittings

Class C

K8

K9

K10

K12

K12

K14

80

4.4

6

6.0

7

8.1

100

4.4

6.0

7.2

8.4

125

4.5

6.3

7.5

8.8

150

4.5

6.3

7.8

9.1

200

4.7

6.3

8.4

9.8

250

5.5

6.8

7.5

9

9

10.5

300

6.2

6.4

7.2

8

9.6

9.6

11.2

350

6.3

6.8

7.7

8.5

10.2

10.2

11.9

400

6.5

7.2

8.1

9

10.8

10.8

12.6

450

6.9

7.6

8.6

9.5

11.4

11.4

13.3

500

7.5

8

9

10

12

12

14

600

8.7

8.8

9.9

11

13.2

13.2

15.4

700

8.6

9.6

10.8

12

14.4

14.4

16.8

800

9.6

10.4

11.7

13

15.6

15.6

18.2

900

11.6

11.2

12.6

14

16.8

16.8

19.6

1000

12.6

12

13.5

15

18

18

21

1200

13.6

13.6

15.3

17

20.4

20.4

22.8

1400

15.7

15.2

17.1

19

22.8

22.8

26.6

1500

16.7

16

18

20

24

24

31

1600

17.7

16.8

18.9

21

25.2

25.2

29.4

1800

19.7

18.4

20.7

23

27.6

27.6

32.2

2000

21.8

20

22.5

25

30

30

35
