aluminum door with glass and hardware for entrence room

Ref Price:
Loading Port:
Shanghai
Payment Terms:
TT OR LC
Min Order Qty:
1000 set
Supply Capability:
20000 set/month

OKorder Service Pledge

Quality Product

Order On-line Tracking

Timely Delivery

OKorder Service Pledge

Credit Rating

Credit Services

Credit Purchasing

Share to:

Product Description:

1.Aluminum Door  are an excellent choice for mainly entrance or commercial,shop and so on , especially in servery situations between outside and inside entertainment areas. They are also the safe choice as you canopen the door to any angle 90/120/150 degree.



2.We offer a range of user friendly options for your open doors: single or double opening panels can be specified, along with double glazing where improved thermal or acoustic performance is required.



PRODUCTS SPECIFICATION





DESCRIPTION

GOOD QUALITY ALUMINUM DOOR

ITEM

JIL-AD-025

OPEN STYLE

HORIZONTAL

PROFILE

Standard aluminum profile

2.0mm thickness

SINGLE/DOUBLE

GLASS

5MM+9A+5MM thickness, DOUBLE GLAZED, double tempered

PROFILE TREATMENT

Dark green color, or customized color, Powder coating finish

HARDWARE

China brand in good quality or German

SEALING STRIP

EPDM sealing strip, or silicon sealant

CERTIFICATE

Send for test and certified if required

PRODUCT FEATURE

SOUND INSULATION

40-45(dB)

WATER TIGHTNESS

400(Pa)

HEAT INSULATION

(W/m2·K)

AIR TIGHTNESS

(m3/h·m)

PAYMENT AND DELIVERY

MOQ

1 (Set)

DELIVERY TIME

15~30 (days)

PAYMENT TERM

L/C, T/T, O/A




Send a message to us:

Remaining: 4000 characters

- Self introduction

- Required specifications

- Inquire about price/MOQ

Q:How does the aluminum door sink?
Do you have three hinges? Are three hinges installed on both sides, the underside of one? If you are starting from the hinges to try to start, if the first two there is a discrepancy you will be asked to increase the changes I asked if all the tune does not line ~ that I feel the glass pad is not correct ~ ~ pad The way wrong! (Your glass is hollow it) The glass mat pad method is not correct The fan is easy to sag! And if you are the whole sinking, you are on the hinge to replace or increase the fixed wire ~ I hope to help you
Q:Titanium Magnesium Alloy Door, Steel Wooden Door Which is more suitable as a bedroom door?
Steel doors should be better on sound insulation.
Q:Repair small hole in metal front door?
I would buy a can of the foam that expands and fill the hole. If it expands out, let it dry thoroughly and cut it off. Then you can sand it, prime it and paint it. Word of warning - the remainder of foam in the can will not be used once the foam coagulates in the tube so fix as much stuff as you can once you start. On the bright side, this stuff isn't that expensive anymore so you won't be out much. Good luck.
Q:Titanium magnesium alloy door can change color?
Can change color. Titanium magnesium alloy door color is generally paint. If you have installed, you need to remove the factory sent to the factory processing, drying.
Q:Production of aluminum doors and windows of the professional qualification certificate how to apply
To the local decoration company asked clear, you can test engineers, construction division
Q:Broken bridge insulation aluminum doors and windows and steel doors and windows which is good
Broken aluminum doors and windows insulation is good: aluminum-plastic composite profiles in the plastic thermal conductivity is low, the insulation effect is better than aluminum 1250 times, Plus a good air tightness, in the cold area despite the outdoor tens of degrees below the room is another world. 2. broken bridge aluminum doors and windows sound insulation is good: its structure has been carefully designed, seams tight, test results, noise 30db, in line with the relevant Standard. 3. Broken bridge aluminum doors and windows impact resistance: As the outer surface of aluminum-plastic composite profile for the aluminum alloy, so it is better than plastic steel window impact Much more powerful. 4. broken bridge aluminum doors and windows of good air tightness: aluminum-plastic composite window at the joints are equipped with multi-channel sealing tops or strips, air tightness for a, Can give full play to air conditioning to pay, and save 50 energy. 5. broken bridge aluminum doors and windows watertight: window and window design with rainwater structure, the rain completely isolated from the outdoor, water-tight meet the country Home related standards. 6. broken bridge aluminum doors and windows fire good: aluminum alloy for the metal material, do not burn. 7. broken bridge aluminum doors and windows anti-theft is good: aluminum composite window, excellent configuration of hardware accessories and senior decorative locks, so that thieves helpless 8. Broken bridge aluminum doors and windows maintenance-free: aluminum-plastic composite profiles are not susceptible to acid-base erosion of ordinary steel about 210 yuan, broken bridge aluminum will 47 0 left and right square
Q:There are several types of aluminum alloy doors and windows profiles
Aluminum alloy doors and windows profiles are: 35 series, 38 series, 40 series, 60 series, 70 series, 90 series. The so-called 35,38 ... ... refers to the width of the main frame of aluminum alloy profiles are 35 mm, 38 mm ... .... Sealed balcony is usually used 70 series or 90 series, if less than 70, the degree of hardness is difficult to guarantee.
Q:Aluminum doors and windows how to nail it?
1. Aluminum doors and windows are generally installed self-tapping screws, can not use nails. Do not go in. 3. Drill hole screwdriver mounting screw. Can also play rivets.
Q:Aluminum alloy door and window frame and hole wall gap for how much, in the specification can be found
The gap between the door frame and the hole is required Wall facade material between the door and window frame and the hole between the gap Water wall 15mm, mortar + coating 20 ~ 25mm. Bricks 25 ~ 30 mm. Stone 40 ~ 50mm (using concrete mouth or increase the sub-box) outside the insulation wall External insulation thickness + Facing material practice gap -10 Note: (1) due to the finishes (including insulation) material thickness requirements, will make the window frame and the hole between the gap increases, when the door When the gap between the window frame and the hole is greater than 35mm, it is necessary to add a concrete mouth or steel sub-frame between the door frame and the hole. The gap between the mouth and the window frame should not be greater than 20mm; sub-frame and the gap between the doors and windows frame is 5mm, sub-frame and the hole side of the gap should not be greater than 20mm; no sub-frame when the finish surface to be pressed window frame 5mm , There are sub-frame when the surface and sub-box top flush. (2) The gap between the threshold of the door frame and the hole shall be adjusted according to the difference between the floor material and the threshold of the door frame. To ensure that the gap between the threshold and the floor (wall) filled with dense and external waterproof integrity, after the completion of the floor of the floor should be high outside the low
Q:Aluminum doors and windows have a sound what is the reason
Ordinary aluminum alloy sealing effect is not good, sometimes the indoor air will produce convection, the gap will be small air convection will produce the sound, check all the windows of the seal, closed, closed, sewn place with stuff Live, it is recommended that you replace the windows, ordinary aluminum alloy, no matter from the closed, insulation, sound insulation is not a good choice, or change the steel flat window or broken bridge aluminum alloy. And are hollow double glass, the effect is very good. But do not be black, and now fake counterfeit too much.
