Item specifice:

Material: Polycrystalline Silicon Max. Power(W): 255 Number of Cells(pieces): 60

Product Description:

255W Poly Solar Panel PV Module with High Quality and Lower Price of PV Solar Panel

Description of PV



Pv solar module:
Scope: 40w - 310w/piece;
Solar cell: High efficient mono/poly crystalline silicon solar cell;
Long lifetime: More than 25years working life;
Tempered glass: High transmission rate glass increase the power output and mechanical strength of Solar module;
Frame: Aluminium alloy, without screw, corner connection;
Junction box: Multi function junction box with by pass diodes and wate proof;
Preventing from bad weather condition such as wind and hails;
Resisting moisture and erosion effectively, not effected by environment;
Certificate: ISO, CE,ROHS,TUV,IEC,CEC,CGC,UL,ETL,MCS,PV CYCLE,3E.
Scope: 40w - 310w/piece;






Solar cell: High efficient mono/poly crystalline silicon solar cell;

Long lifetime: More than 25years working life;
Tempered glass: High transmission rate glass increase the power output and mechanical strength of Solar module;
Frame: Aluminium alloy, without screw, corner connection;
Junction box: Multi function junction box with by pass diodes and wate proof;
Preventing from bad weather condition such as wind and hails;
Resisting moisture and erosion effectively, not effected by environment;
Certificate: ISO, CE,ROHS,TUV,IEC,CEC,CGC,UL,ETL,MCS,PV CYCLE,3


Technology with PV



ITEM NO.:

Poly 156*156 cell ,60pcs . Power range from 230Wp-260Wp

Maximum Power(W)

 230

235

240

245

250

 255

 260

Optimum Power Voltage(Vmp)

 29.4

29.5

29.7

30.1

30.3

 30.5

30.7

Optimum Operatige Current(Imp)

 7.83

7.97

8.08

8.14

8.25

 8.37

 8.48

Open Circuit Voltage(Voc)

 36.7

36.8

36.9

37.1

37.3

 37.5

 37.7

Short Circuit Current(Isc)

 8.52

8.59

8.62

8.65

8.69

8.73

 8.78

Solar Cell:

156*156 Poly

Number of Cell(pcs)

6*10

Brand Name of Solar Cells

CNBM

Size of Module(mm)

1650*992*40/45/50

Cable & Connector Type

Pass the TUV Certificate

Frame(Material Corners,etc.)

Aluminium-alloy

Back sheet

TPT

Weight Per Piece(KG)

19.5KG

FF (%)

70-76%

Junction Box Type

Pass the TUV Certificate

Tolerance Wattage(e.g.+/-5%)

±3%, or 0-3%

Front Glass Thickness(mm)

3.2

Temperature Coefficients of Isc(%)

+0.04

Temperature Coefficients of Voc(%)

-0.38

Temperature Coefficients of Pm(%)

-0.47

Temperature Coefficients of Im(%)

+0.04

Temperature Coefficients of Vm(%)

-0.38

Temperature Range

 -40°C to +85°C

Surface Maximum Load Capacity

5400Pa

Allowable Hail Load

23m/s ,7.53g

Bypass Diode Rating(A)

12

Warranty

90% of 10 years, 80% of 25 years.

Standard Test Conditions

AM1.5   1000W/ 25 +/-2°C

Packing

 carton or pallet

1*20'

14 Pallets / 316pcs

1*40'STD

25 Pallets / 700pcs







Production with PV









Solar panel quality and warranty

1. Peak power of single module in guaranteed in +-3%power tolerance.

2. Average power of modules in single order is guaranteed not less than the peak power

3. Rigorous quality control meets the highest international standard

5.5 years limited warranty on material and workmanship

 6.10 years and 20 years limited warranty for minimum power output.



Aboutus with PV

CNBM International Corporation, as an important external business platform of CNBM Group, plays as a role to export solar products produced by CNBM. Headquartered in Beijing, We have entered into Solar PV industry since 2005. CNBM Solar is specialized in PV power systems which takes advantage of reliable supplying, convenient installation and free maintenance, and has been used widely, and it is the compensation and substitution of normal power supply. We provide power solutions for home, business and industrial customers, and provide off-grid PV systems for rural area. Our company not only can supply high quality solar Products, but also provides professional system Solutions and high quality services.





Question&Answer



How to buy your ideal products?



A: Providing the information of your projects required, then we will make the most suitable solution and products.



How to pay?


A:TT will be more appreciated. 30% deposit after oder confirmed, 70%  before shipment.



What is the delivery time?


A: It depends on order quantities. Generally, the delivery time will be within 15 to 30 days.



How to pack the products?


A: We use standard package, carton boxes, wooded pallet. If you have special

package requirements,  we will pack as required. The fees are negotiable.



How to install after the goods arriving destination?


A: We will provide detailed illustrations to you. If it is necessary, we will send technicians to help you. However, the visa fee, air tickets, accommodation, wages will be paid by buyers.





Send a message to us:

Remaining: 4000 characters

- Self introduction

- Required specifications

- Inquire about price/MOQ

Q:question about solar panels....?
They create electricity from light energy provided by the sun....
Q:how are solar panels practical?
Solar Panels are practical because they provide electricity to your home directly avoiding the rates paid to the utility. They are pay themselves off in 5 years or less and supply an income stream in NJ for 5 years!
Q:Solar panel wiring trouble.?
You are probably wiring them incorrectly: with the positive on panel A connected to negative on panel B; and the negative on panel A connected to the positive on panel B. If you want then connected in parallel, connect the positive on panel A to the positive on panel B and the negative on panel A connected to the negative on panel B. But you will only get vdc. You can't get .5 volts from two volt sources. You can get 2 volts by connecting the panels in series.
Q:Best orientation for my solar panel?
Typically, solar panels are installed facing the same as your latitude = 2 degrees to the North measured from horizontal. 60 degrees from vertical = 30 degrees from horzontal will give almost as much power in June as in December = beginning of Summer. You can face your panels straight up = zero tilt from vertical = better for December/ not so good in June. Usually, the same tilt as your North facing roof is best as it simplifies installation and reduces wind loading. Shade from trees etc will much reduce the power you get. Neil
Q:Why are solar panels only 0% efficient?
Mainly due to reflection (micro-structuring of the surface helps here), incorrect wavelength of the light (the panel is only sensitive to a certain wavelength range) and heating of the panel (due to the incident light/thermal radiation). The remainder is either reflected or absorbed by the cell and re-emitted as heat. Absorption by e.g. the glass panel is slight (a few %), as is absorption/reflection by the necessary surface contacts (again, a few %). Higher efficiency is possible, but brings its own drawbacks (like higher cost). You could now go into two directions: - high efficiency cells/panels with (likely) higher cost and complexity for mounting (like lens or mirror based systems, aka concentrator systems, that increase the light level on the cells in order to increase efficiency) - low cost systems (cheap as dirt) that will allow you to cover every surface of a building, efficiency is less important if you can compensate by a much larger covered area As to the efficiency limit: there is a theoretical limit (from thermodynamics - don't ask me how or why) in the range of 30...40%, depending on which publication you want to believe in.
Q:How do you connect a solar panel to a motor from an RC car?
can increase your voltage from a single solar panel. In combination with a large capacitor, you could deliver short bursts of power to the motor which would allow intermittent operation.
Q:How do you set up 30w solar panel?
With a 30 watt panel, producing about 2 amps, your not going to have much power from that. A 22 AH battery will give you 2 AH of usage. A battery should never be drained below 50%. What this works out to be is simply Amp draw for 2 hours. Which equals to 2V light bulb that draws amp for 2 hours. Not much. Now to replace that usage with your 30 watt panel, provided the panel is clean and in max sunlight, it will take 6 hours. If you attach an inverter to your system for 5 Volt Usage then the DC voltage drawn from the battery is very high. Example: Say you use a 5 Volt component that requires 50 Watts per hour to operate. The inverter will draw 5 Amps out of the Battery every hour to operate that component. That gives you and /2 of use before the battery is down to 50%.. Maybe that will be enough to charge up a standard Laptop battery. I have 2 30 Watt panels that produce 5 Amps, 4 6V batteries that have 480 AH and a 25 Amp Controller with a booster that increase the amp output to 20 Amps per hour. I live full time in an RV and raise the panels to get max output when I am parked. This system provides me with all the 5V throught the 500 Watt inverter that I need. Good luck on you system.
Q:Is it worth installing solar panels on a house that has no South-facing roof?
Depends how much sun you get. Even if you don't face south, you could still be able to harvest a lot of energy from the sun. You could install panels transversely so they face south to increase sun exposure, but this might not look so nice. Or you could move your house to the Southern hemisphere, when your solar panels should face north. Or install miniature windmills on your roof instead.
Q:Who made solar panels?
Many people think that solar power is a new concept. That couldn’t be farther from the truth. Harnessing power from the sun has been dated back to ancient civilizations. The below link is a timeline researched by the Department of Energy that outlines the major historical milestones of solar power.
Q:solar panel help needed ?
You need to know how many solar cells are in the panel and what is the rated current each cell will produce. This information should be listed on the panel. Each cell will produce from 0.5 to 0.55 volts DC per cell and each cell will produce a current that is dependent on the size of the cell and the type of material the cell is made from. If the cells are connected in series then the voltage of each cell will add together, that is if you have 30 cells connected in series they should generate about 5 to 6.5 volts DC. If each cell generates .2 amps, then you multiply the voltage of 5 volts DC times .2 amps DC equals 8 watts of power. The current of each cell does not add together when you connect the cells in series only the voltage of each cell. If you connect the 30 cells in parallel then the current of each cell adds together but the voltage of each cell does not. That is 0.5 Volts DC times 36 amps equals 8 watts. The power (watts) produced will be the same. See our blog on the products page to see how to connect solar cells in series and in parallel. We also have a PDF file of solar cells and their rated output current sorted by watts per area and their manufacturer.
