240W Poly Crystalline Solar Panel for Sale

Ref Price:
Loading Port:
Shanghai
Payment Terms:
TT OR LC
Min Order Qty:
10000 watt
Supply Capability:
1000000 watt/month

OKorder Service Pledge

Quality Product

Order On-line Tracking

Timely Delivery

OKorder Service Pledge

Credit Rating

Credit Services

Credit Purchasing

Share to:

Item specifice:

Material: Polycrystalline Silicon Max. Power(W): 240 Number of Cells(pieces): 60

Product Description:

Product Description

240W Poly Crystalline Solar Panel

.jpgProduct Highlights:

Specs

Electrical Characteristics
Maximum Power [Pmax]240W
Power Tolerance+/-3%
Maximum Power Voltage [Vmp]29.8V
Maximum Power Current [Imp]8.06A
Short-Circuit Current [Isc]8.62A
Open-Circuit Voltage [Voc]37.0V
Module Efficiency14.75%
Max. System Voltage1000VDC
Cell Size and SeriesPoly 156*156  60pcs (6*10)
Temperature Coefficient of Pmax- 0.47% / º C
Temperature Coefficient of Voc- 0.33% / º C
Temperature Coefficient of Isc0.05% / º C
Mechanical Characteristics
Dimension (mm)1640*992*40
FrameAnodized Aluminium Alloy
Glass3.2mm,High Transmission,Tempered Glass
Junction box & CableIP65 Rated weatherproof connectors
Cable: TUV 1x4.0mm2 / UL12AWG,Length:900mm
Weight19.0Kgs

Industry-leading Warranty:
Warranty on material and workmanship: 10 years
Guaranteed output of 90% after 12 years and 80% after 25 years.

FAQ

1.Price per watt?

It depends on the quantity, delivery date and payment terms.

2.Parameter of the module?

We have different series of panels in different output, both c-si and a-si. please take the specification sheet for your reference.

3.Can you provide the peripheral products of the solar panels, such as the battery, controller etc.?

We have two companies(CNBM International & CNBM engineering Co.) with different approaches. We can supply not only the solar module but also Solar Cells, off grid solar system, even service with on grid plant.

4.Warranty policy?

Our product performance guarantees for 25 years

• 12 years guarantee for workmanship

• Timeliness of delivery

• Quality Products certified (TÜV, UL, CE, ISO)

5.Lead time?

In 3 days after purchasing, we will arrange the factory delivery ASAP. The specific time of receiving is related to the state and position of customers. Commonly 7 to 10 working days can be served.

Send a message to us:

Remaining: 4000 characters

- Self introduction

- Required specifications

- Inquire about price/MOQ

Q:What is the working principle of solar panels?
No matter what kind of material to make the battery, the general requirements for solar cell materials are
Q:What is the main material for making solar panels?
You can also according to their own needs, according to the power to buy a good package of solar photovoltaic products.
Q:What is the principle of solar panels to convert solar energy into electricity?
Solar cells are a pair of light response and can convert light energy into electrical devices. There are many kinds of materials to produce photovoltaic effects, such as: monocrystalline silicon, polycrystalline silicon, amorphous silicon, gallium arsenide, selenium and other copper. Their power generation principle is basically the same, now the crystal as an example to describe the process of photovoltaic power generation.P-type crystalline silicon doped with phosphorus can be N-type silicon, the formation of P-N junction.
Q:Single crystal solar panels and polycrystalline solar panels
Monocrystalline silicon solar cells are mainly made of monocrystalline silicon, compared with other types of solar cells, monocrystalline silicon cell conversion efficiency of the highest. In the early days, monocrystalline silicon solar cells occupied most of the market share, in 1998 after the retreat of polysilicon, the market share accounted for second. Due to the shortage of polysilicon raw materials in recent years, after 2004,
Q:What is the difference between solar panels and light panels?
Crystalline silicon cell conversion rate, rich in raw materials, is a large-scale commercial production of the battery, but the crystal silicon battery brings the harm can not be ignored. Crystal silicon series of batteries have a "three high more than a" common problem. High cost, high energy consumption, high pollution, byproducts and other shortcomings.
Q:Can solar panels be connected directly to motor?
The sun is irradiated on the semiconductor p-n junction to form a new hole-electron pair. Under the action of the p-n junction electric field, the holes flow from the n region to the p region. The electrons flow from the p region to the n region, and the current is formed after the circuit is turned on.
Q:Composition and function of solar panels
The demand for polysilicon is mainly from semiconductors and solar cells. According to the different requirements of purity, divided into electronic and solar level.
Q:Polycrystalline solar panels are good or single crystal solar energy is good
Polycrystalline silicon solar cell production process and monocrystalline silicon solar cell almost, but the polysilicon solar cell photoelectric conversion efficiency will have to reduce a lot of its photoelectric conversion efficiency of about 12% (
Q:The voltage and power problems of solar panels
In general, the charging voltage is 1.5 times the battery voltage as well, that is 12V battery pack, select the 18V solar panels just.
Q:How many solar panels have ah?
But in reality, the need for solar panel power and solar charger to find a balance in the portability. It is generally believed that the minimum power of the solar charger can not be less than 0.75w, and the secondary power solar panel produces 140mA of current under standard light. In the general sunlight generated by the current at 100mA or so, if less than the secondary power charging current is too small,
